Flexible Part Feeding Systems SW-170

Swoer Custom Flexible Part Feeding Systems Manufacturer and Supplier in China

– MOQ: 1pcs
– OEM/ODM service offered
– Accept customization (specifications, color, design, etc.)

If you want to get paper box prices, please get in touch with us.

SW-170 commonly used for screening small metal parts (such as steel sheets, springs, etc.) and small connectors.




Flexible Part Feeding Systems SW-170 Specifications

DescriptionSW-170
Dimension(mm)240*150*101
Feeder’s dimension(mm)170*140*19
WeightAbout 3.9kg
VoltageDC20-30V(Recommended 24V)
Maximum current6A
Operation formMove up, down, left, right, top left, bottom left, top right, and bottom right, center up and down, center left and right, shake and flip, and directly vibrate to feed
Frequency10-131Hz
Operation noise＜50dB
Maximum load0.5kg
The weight of a single flipped material＜15g
Signal interactionTCP/IP communication
I/O interface

Flexible Part Feeding Systems SW-170 Dimension Drawing

flex feeder system SW-170 dimension drawing
